COMBOVE TYPE 3120-1000KV

$105.00
In stock
SKU
TYPE 3120-1000KV
Apply Payment Method
Apply Payment Method
  • Extreme lightweight design
  • High torque and low temperature rise
  • 180 degree NdFeB magnet

3120 motor

Specifications

Stator Diameter 31 mm
Stator Thickness 20 mm
No. of Stator Arms 12
Magnet Poles 10
Motor Wind 7T+6T Turn Delta
Motor Wire 1-Strand 0.86 mm
Motor Kv 1000KV RPM/Volt
No-Load Current (IO/10v) 1.17 Amps
Motor Resistance (RM) 0.033 Ohms
Max Continuous Current 70 Amp
Max Continuous Power 1500 Watt
Weight 155 Grams
Outside Diameter 40 mm
Shaft Diameter 5 mm
Body Length 41.5 mm
Overall Shaft Length 63 mm
Max Lipo Cell 6s
Peak Continuous Current 90 Amps (4 seconds)
Peak Continuous Power 2000 Watts (4 seconds)
Motor Timing 5deg~12deg
Drive Frequency 8kHz~32khz
